11.6 inch 1920*1080 TFT module display
11.6 inch 1920*1080 TFT module display
11.6 inch 1920*1080 TFT module display
11.6 inch 1920*1080 TFT module display

11.6 inch 1920*1080 TFT module display

Item 11.6inch IPS 1920*1080TFT display
Model No. PV116004S0730E
Resolution 1920*1080
Outline Dimension (mm) 267.72*164.42*6.1
Active Area (mm) 256.320*144.180
Viewing Angle All
Brightness 1000nits
Interface eDP
Backlight 4*10LED
Driving IC /
PIN No. 30
Operating Temperature -20~70C
Storage Temperature -30~80C
Touch screen Can custom resistive and capacitive touch screen
Application Medical, hand-held device, industrial or outdoor,
advertisement and thermostat, automotive

For product pricing,customization,or other inquiries:

INQUIRY

Share to:

  1. Stable supply
  2. Full/All/Wide viewing angle
  3. 1000nits brightness/Sunlight readable/High brightness/Outdoor
  4. Can custom resistive touch and capacitive touch
