5.5-inch 720*1280 dots LCD module IPS TFT-LCD

Item 5.5inch 720*1280 LCD with capacitive touch
Model No. PV05500TD29A-C
Resolution 720*1280
Outline Dimension (mm) 76.5*149.5*2.73
Active Area (mm) 68.04*120.96
Viewing Angle All
Brightness 360nits
Interface MIPI 4Lane
Backlight 7*2LED
Driving IC HX8394-F210PD250
PIN No. 29
Operating Temperature -20~70C
Storage Temperature -30~80C
Touch screen Capacitive touch
Application Mobile phone, telecom device, handheld device, video door

For product pricing,customization,or other inquiries:

INQUIRY

Share to:

  1. 5inch 720*1280 LCD with capacitive touch
  2. Full/All/Wide viewing angle
  3. Support MIPI 4 lane interface.
  4. Capacitive Touch optional
