7.0-inch TN LCD Module – 800×480, 500nits, 24-bit RGB, Touch Optional

Key Specifications

Model: PV07048Y0150Z

Resolution: 800×480

Active Area: 154.08 x 85.92 mm

Brightness: 500 nits

Interface: 24-bit Parallel RGB

Touch Options: Resistive/Capacitive (customizable)

Temperature Range: -20°C to +70°C

Backlight: 3×9 LED array

Connector: 50-pin

Features
High Clarity: 500nits brightness for indoor/outdoor readability.
Dual Touch Support: Flexible resistive or capacitive input.
Compact Design: Slim profile (5.7mm thickness) for space-constrained devices.
Wide Compatibility: Ideal for medical, industrial, and consumer electronics.

For product pricing,customization,or other inquiries:

Share to:

Description

Durable 7-inch TN LCD module (800×480) with 500nits brightness, 24-bit RGB interface, and dual touch options. Ideal for industrial/medical devices.

Applications

Industrial control panels

Medical monitoring devices

Digital photo frames & portable DVD players

Video doorbells & IP phones

Why Kingtech?

Stable Supply: Reliable bulk order fulfillment.

Custom Solutions: Touchscreen customization and firmware support.

Rugged Build: Tested for extreme temperature performance.

Order Now
Contact for MOQ, pricing, and technical specifications.

Optimized for OEMs requiring a compact, high-performance display for diverse commercial and industrial applications.
