7inch WVGA LCD module 1000nits brightness Outdoor
| Item | 7.0 inch TFT 800x480module display |
| Model No. | PV07037Y0150N |
| Resolution | 800×480 |
| Outline Dimension (mm) | 164.9*100*5.7 |
| Active Area (mm) | 154.08*85.92 |
| Viewing Angle | All |
| Brightness | 1000nits |
| Interface | 24bit Interface |
| Backlight | 3*9LED |
| Pin nums | 50 |
| Driving IC | / |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | with capative touch screen |
| Application | Outdoor,industrial equipment, medical products, white goods, POS system, Kiosk, and so on |
For product pricing,customization,or other inquiries:
Share to:
- TN TFTLCD display
- 800×480 /WVGA
- Stable supply
- Full/Wide/All/IPS viewing angle
- 24 bit RGBinterface
- 1000nits brightness/High brightness/Sunlight readable/Outdoor
- With/without capacitive touch and resistive touch
- Outdoor device, industrial equipment, medical products, white goods, POS system, Kiosk and so on
