8.4 inch 800×600 SVGA TFT LCD module LVDS interface
| Item | 8.4inch 800×600 LVDS interface display |
| Model No | PV084000AR20A |
| Resolution | 800×600 |
| Outline Dimension | 203*142.5*5.7 |
| Active Area(mm) | 170.4*127.8 |
| Interface | LVDS 6/8bit |
| Brightness | 350nits |
| Driver IC | NT51008B*2+NT52002*1 |
| Viewing Angle | 12 O’clock |
| LED life | 50000h |
| Display Mode | TN / Transmissive / Normally white |
| PIN | 20 |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touchscreen | Capacitive touchscreen |
For product pricing,customization,or other inquiries:
Share to:
- 800×600 / SVGA
- LVDS interface
- Landscape / Horizontal
- Stable supply
- HDMI board / Convert board
- Capacitive touchscreen to be customized
