9.0 inch 3840×2400 2K Mono LCD
| Item | 9.0 inch 3840×2400 2K Mono LCD |
| Model No. | PV09005P0160F |
| Resolution | 3840*2400 |
| Outline Dimension (mm) | 202*127 |
| Active Area (mm) | 192.0*120.0 |
| Viewing Angle | All |
| Brightness | / |
| Interface | LVDS |
| Backlight | / |
| Driving IC | ST5892B |
| PIN No. | 60 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Customized |
| Application | medical high resolution instrument, Surveillance video, Transportation Camera,3D printer, Automotive, E-bike, Ship. |
For product pricing,customization,or other inquiries:
Share to:
- Mono/Black&white display
- Special Size – 9inch
- High resolution 3840×2400, 2K resolution
- LVDS interface
- Full/Free/All/Wide/IPS Viewing angle
