Kingtech 12.1 inch 1024*768 TFT display
| Item | 12.1inch TN 1024*768 TFT display |
| Model No. | PV012105Y0120F |
| Resolution | 1024*768/XGA |
| Outline Dimension (mm) | 279.0*209.0*9.0 |
| Active Area (mm) | 245.76*184.32 |
| Viewing Angle | 6 O’clock |
| Brightness | 350nits |
| Interface | LVDS |
| Backlight | / |
| Driving IC | / |
| PIN No. | 20 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial |
For product pricing,customization,or other inquiries:
Share to:
- 1 inchTFTdisplay
- 1024*768/XGA
- Stable supply
- 6 O’clock
- LVDSinterface
- 350nits brightness/Sunlight readable/High brightness
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial
