Kingtech 2.0 inch 240×320 resolution TFT LCD display
| Item | 2.0 inch 240×320 small size transflective LCD display |
| Model No. | PV02016Y0840U |
| Resolution | 240*320 |
| Outline Dimension (mm) | 38.52*52.74*2.69 |
| Active Area (mm) | 30.60*40.80 |
| Viewing Angle | 8 O’clock |
| Brightness | 140nits |
| Interface | MCU 、RGB、SPI 3len |
| Backlight | 1*4LED |
| Driving IC | ST7789V2 |
| PIN No. | 40 |
| Operating Temperature | -30~70C |
| Storage Temperature | -40~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, smart watch, E-bike, Outdoor |
For product pricing,customization,or other inquiries:
Share to:
- Small LCD display
- IPS /Free/All/Wide viewing angle
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial, smart watch
- Transflective /Sunlight readable/140nits/Outdoor
