Kingtech 3.5 inch 240×320 resolution TFT LCD display
| Item | 3.5 inch 480*640 IPS viewing angle LCD display for outdoor |
| Model No. | PV03525D0120Y |
| Resolution | 480*640 |
| Outline Dimension (mm) | 61.00*81.75*2.6 |
| Active Area (mm) | 53.28*71.04 |
| Viewing Angle | All |
| Brightness | 900nits |
| Interface | MIPI |
| Backlight | 6*1LEDs |
| Driving IC | ILI9806E |
| PIN No. | 20 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, E-Bike, EV-chargers |
For product pricing,customization,or other inquiries:
Share to:
- Small LCD display
- IPS/Free/All/Wide viewing angle
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial
