Kingtech 4.0 inch 480*800 TFT display supply very stable.
| Item | 4. 0 inch IPS 480*800 TFT display |
| Model No. | PV04005TD25E-CO |
| Resolution | 480*800/WVGA |
| Outline Dimension (mm) | 62.5*111.04*3.47 |
| Active Area (mm) | 51.84*86.4 |
| Viewing Angle | All |
| Brightness | 400nits |
| Interface | MIPI-2 Lanes |
| Backlight | 4*2LED |
| Driving IC | ST7701S |
| PIN No. | 25 |
| Operating Temperature | -20~60C |
| Storage Temperature | -30~70C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, Hand-held device, Industrial |
For product pricing,customization,or other inquiries:
Share to:
- 4.0 inchTFTdisplay
- 480*800/WVGA
- Stable supply
- All/Full/Wide/IPS viewing angle
- MIPI-2 Lanesinterface
- 400nits brightness/Sunlight readable/High brightness
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial
