Kingtech PV07053T0124E-CO is a 7-inch LCD module using IPS TFT-LCD technology
| Item | 7.0 inch IPS 1280*800 LCD module with CTP |
| Model No. | PV07053T0124E-CO |
| Resolution | 1280*800 |
| Outline Dimension (mm) | 165.62*107.45*2.8 |
| Active Area (mm) | 150.72*94.2 |
| Viewing Angle | IPS |
| Brightness | 250nits |
| Interface | MIPI |
| Backlight | 5*4LED |
| Driving IC | ILI9881 |
| PIN No. | 24 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Optional |
| Application | Industrial,Medical,Telecom, Smart Home, tablet PC, 5G device |
For product pricing,customization,or other inquiries:
Share to:
- WXGA resolution
- Landscape, Horizontal shaped
- With CTP, OCA bonding, better fit for LCD module and CTP
- MIPI interfaces, a wide range of applications and is mainly used as a serial communication interface for mobile devices and embedded systems.
Kingtech is one of the leading TFT LCD display OEM/ODM manufacturers in China since 2003. Customization is allowed for projects such as industrial devices, medical, POS, logistics devices, smart home applications and etc.
To provide a one-stop LCD display solution. During the last 17 years, based on LCD manufacturing as our center, we gradually expand to the TFT capacitive touchscreen, driving board, software hardware design, and complete industrial computer solution.
As a professional LCD screen supplier/ LCD display supplier/ LCD panel company/ LCD module manufacturer, Kingtech LCD aims to provide a one-stop service and solve your problems. With a strong LCD Display module R & D team and strict quality management of IS09001, IS01400ATF16949 certificates.
